BLUE WATER | EXPRESS SERIES
EXPRESS
The Blue Water Express series of watermakers is designed to fit into the tight spaces of small and mid-sized yachts. These systems offer semi-automatic operation utilizing traditional switches and a manual high-pressure valve. An electronic controller automatically diverts product water to the storage tank and LED lights to indicate product water salinity and system status. The Express series includes Fresh Water Flush system as standard.
FEATURES
- Semi-automatic operation
- Fresh water flush system
- High rejection membranes
- Product water carbon filter
- Dual voltage 50/60Hz motors
- Stainless steel booster pump shaft
- Designed for ease of service & maintenance
- Installation Kit
- Optional Magnetic Drive Booster Pump
Advantages
- One-touch operation
- Simple controller with digital display
- Low-pressure safety switch
- High-pressure monel transducer
- Adjustable FWF interval up to 10 days
- Optional remote control
Specifications
| Model | Membranes | Production / HR | Production / 24HR | Weight |
|---|---|---|---|---|
| EXS 360 | 1 | 15 Gal / 57 L | 360 Gal / 1,360 L | 140lbs / 64kg |
| EXS 600 | 1 | 25 Gal / 95 L | 600 Gal / 2,270 L | 160lbs / 73kg |
| EXS 800 | 1 | 33 Gal / 126 L | 800 Gal / 3,030 L | 170lbs / 77kg |
| Model | Feed Flow GPM | Booster Pump HP | kW | HP Pump HP | kW | Run Amps (110/220V) | Start Amps (110/220V) |
|---|---|---|---|---|---|
| EXS 360 | 1.5 | 0.5 | 0.37 | 1 | 0.74 | 13A / 6.5A | 72A / 36A |
| EXS 600 | 3 | 0.5 | 0.37 | 2 | 1.47 | 26A / 13A | 94A / 47A |
| EXS 800 | 3 | 0.5 | 0.37 | 2 | 1.47 | 26A / 13A | 94A / 47A |
