LOFRANS X2 - Vertical Windlass Chrome Bronze

Anchor & Docking

LOFRANS X2 - Vertical Windlass Chrome Bronze

Product Name Part Number Stock Price Qty
1500W/12V 10DIN766 187273 In Stock $2,199.29
G+D 1500W/12V 10DIN766 187274 Low Stock $2,284.15
G+D 1500W/24V 10DIN766 187276 Out of stock $2,732.22
G+D 1000W/12V 8-5/16''BBB-5/16''HT 473212 Low Stock $2,284.15
1000W/12V 8-5/16''BBB-5/16''HT 473213 In Stock $2,284.15
G+D 1000W/24V 8-5/16''BBB-5/16''HT 473255 Out of stock $2,199.53
G+D 1500W/12V 8Mil DIN766 ALLOY (not CHROME BRONZE) 600057 Out of stock $2,284.15
G+D 1500W/12v 10mm ISO4565, Alloy Base 600056 Low Stock $2,284.15

The "X" vertical windlasses are suitable for sail and motor boats from 6m to 27m in length. They have different motorization attributes according to each model.

The standard features that you can meet in every X series windlass are:

Watertight stainless steel ball bearing in the base (for better functionality and zero maintenance) which is a unique feature in the windlass market.
The clutch is made by two conical discs connected to the main shaft by two parallel planes on the shaft, in order to avoid using keys and allocate the weight load properly.
The electric motor and gearbox are connected by a particular coupling that is made by a socket for easier maintenance.
There is a sensor in the base and a magnet into the gipsy so they can be connected to a chain counter.
Manual override so that the chain or rope can be recovered manually in case of electric function failure.
